JBL AMPLIFIER STAGE A9004
JBL AMPLIFIER STAGE A9004
JBL AMPLIFIER STAGE A9004
JBL AMPLIFIER STAGE A9004
JBL AMPLIFIER STAGE A9004

JBL AMPLIFIER STAGE A9004

0.0 rating

POWER YOU WILL FEEL AT YOUR CORE

JBL Stage Amps are available in a variety of configurations, delivering the right power and number of channels for full-range and subwoofer applications. For more than four decades, JBL has made the audio experience a lot more satisfying for the car audio enthusiast. With a broad array of loudspeakers, amplifiers and subwooers available, you can drive with ease and exhilaration. These compact amps are equipped with all the important inputs and user controls including a bass EQ as well as LPF and HPF crossover controls for tailoring sound to suit the characteristics of different vehicles. The Stage Amps are easily installed and amazingly reliable—and once they turn on, they’ll make a transducer sit up and sing.
Read More
₱10,985.00

In stock

Add to Wishlist
Add to Wishlist
Compare  Copy Link

VALUE ENGINEERED

Stage amplification provides true JBL performance at an affordable price while now lacking the features needed at properly tune and optimize performance.

COMPACT FOOTPRINT

With it becoming more and more difficult to find spacious locations for amplifier mounting. Stage has been develop in a small compact from factor to allow more location versatility.

FULL ON BOARD PROTECTION

Stage amplification has on board circuitry to protect them from short temperature, overvoltage and undervoltage. An LED indicator is inluded on all four modelsto let you know when one o0f this condutions exists.

RELIABILTY

JBL is one of the greatest audio brands in the world. This is not a coincidence given the arduos testing the quality control. We take our craft seriously and want every consumer to have a word class experience that last and last

INPUT LEVEL CONTROL

When Low level inputs are used, this control adjust the input sensitivity between 200mVrms and 5.0Vrms. When High inputs are, this control adjust the input sensitivity between 0.5Vrms and 15Vrms.

SWITCHABLE BASS EQ

This provides an available bass boots at 45hz of 6db or 12db, serving as a great tool to optimize subwoofer and loudspeaker performance based on location and enclosure type.



General Specifications

Power Output
90Wx4@4ohms
Frequency Response
20-20kHz±1dB
THD@ROP
1%
Input Sensitivity
0.2V-5V
High Pass Filter, Variable
32 -320Hz
Low Pass Filter, Variable
32 -320Hz
Bass EQ@45Hz
0-12dB
Protection
DC, OVP, UVP, OCP, OTP.
